Characteristics of the machine:
1. Double powers, double oil pumps, double motors and double oil coolers are applied for ther two axies to work independentlyl.
2. The oil system is unique in design, with good stability, faster lift-up and lift-down speed compared with other brands during unloading /loading mold.
3. High vacuum and the average pumping method are applied for the manufacture of stable products and improving the quality and productivity.
4. The pedestal vacuum oxygen tank provides large oxygen storage space.
5. The new mold raising mechanism design has the advantages of long working life, quiet mold-unloading/loading, fastness and stability.
6. This is suitable for the highly precise products such as Melamine, rollers, shoes, medical drug pulgs, automobile parts, shake-proof products, gaskets, conductive products and electronic equipments. etc.
Model Data:
| MODEL |
DHV200T |
DHV250T |
DHV350T |
DHV500T |
| TONNAGE |
200T |
250T |
350T |
500T |
| MAX. SYSTEM PRESSURE |
21MPA |
21MPA |
21MPA |
21MPA |
| CLAMPING STROKE |
300MM |
300MM |
300MM |
300MM |
| RAPID CLAMPING SPEED |
≥ 60MM/S |
≥ 60MM/S |
≥ 60MM/S |
≥ 50MM/S |
| HEATING PLATE SIZE |
505X510MM |
570X610MM |
700x700MM |
800X800 |
| DAYLIGHT |
300MM |
300MM |
300MM |
350MM |
| MAX. TEMPERATURE |
250° C |
250° C |
250° C |
250° C |
| VACUUM COVER TRAVEL |
150MM |
150MM |
150MM |
150MM |
| MAX. EJECTOR FORCE |
60KN |
60KN |
100KN |
100KN |
| OPTIONAL |
2RT/3RT/4RT |
2RT/3RT/4RT |
2RT/3RT/4RT |
2RT/3RT/4RT |
| EJECTOR STROKE |
250MM |
250MM |
250MM |
250MM |
| MOTOR POWER |
11.0KW |
11.0KW |
13.0KW |
13.0KW |
| HEATING POWER |
15.3KW |
18.6KW |
20.6KW |
27.8KW |
| MACHINE SIZE |
2200X3500X2800MM |
2550X3800X3000MM |
2850X4000X3200MM |
3100X4200X3400 |
| OIL TANK CAPACITY |
500L |
520L |
670L |
800L |
